ASA Hollow Photovoltaic Monowatt

Category:

Product

Retail price

0.0

元

Market price

0.0

元

Number of views:

1000

Product serial number

Quantity

Stock:

Models

Projection width

Effective width

Thickness

The height of the wave

Color

T770-385-45

816mm

770mm

10mm

45mm

Beige, blue, silver gray

The hollow photovoltaic integrated tile, with a“工” shaped reinforced lattice hollow structure between the surface and the bottom layer, not only has the function of enhancing the tile type rigidity, but also forms a natural air barrier, improve product sound insulation, heat insulation function.
The special buckle structure of the left and right side wave of the hollow photovoltaic integrated tile ensures the regular and even wave shape, and has the function of rainproof and siphon.
The hollow photovoltaic integrated tile with high strength, good rigidity, fire-retardant (B1) , heat insulation, acid and alkali resistance, heat resistance, waterproof, sound insulation, insulation, lightning protection and so on.
The hollow photovoltaic integrated tile can be used as a single roof tile, or can be used with the company's aluminum alloy trapezoidal fixture, which can adapt to the installation solar cell, suitable purlin spacing design does not need“Guide rail” can be covered with photovoltaic panels, every 10,000 square watts of roof can be installed about 1.5 MW, high effective utilization.
